Here is my example.

library(ggplot2)

my_df <- data.frame(x = c(1,2,3), y = c(4,5,6), y_min = c(1,1,2),
                    y_max = c(7,8,8))
ggplot(data = my_df)
    geom_line(aes(x = x, y = y, color = "blue"))
    geom_ribbon(aes(ymin =y_min, ymax =y_max, x= x), fill = "grey70")

I would like to get back something resembling line plot and confidence interval around it, but I am only getting confidence interval (ribbon) not the main line.

What am I missing?

CodePudding user response：

We could set alpha = 0.3 to see the line and change grey70 to grey grey12:

ggplot(my_df)   geom_line(aes(y=y, x=x, colour = "blue"))
  geom_ribbon(aes(ymin=y_min, ymax=y_max, x=x, fill = "band"), alpha = 0.3)
  scale_colour_manual("",values="blue")
  scale_fill_manual("",values="grey12")
