I'm trying to find a way to subtract a SVG path from another, similar to an inverse clip mask. I can not use filters because I will need to find the intersection points of the compound path with other paths. Illustrator does this with the 'minus front' pathfinder tool like this:
The path of the red square before subtracting:
<rect x="0.5" y="0.5" width="184.93" height="178.08"/>
After subtraction:
<polygon points="112.83 52.55 185.43 52.55 185.43 0.5 0.5 0.5 0.5 178.58 112.83 178.58 112.83 52.55"/>
I need this to work with all types of shapes, including curves. If it matters, the input SVGs will all be transformed into generic paths.
CodePudding user response：
You might use paper.js for this task.
The following example also employs Jarek Foksa's pathData polyfill.
paper.js example
var svg = document.querySelector("#svgSubtract");
// set auto ids for processing
function setAutoIDs(svg) {
let svgtEls = svg.querySelectorAll(
"path, polygon, rect, circle, line, text, g"
);
svgtEls.forEach(function(el, i) {
if (!el.getAttribute("id")) {
el.id = el.nodeName "-" i;
}
});
}
setAutoIDs(svg);
function shapesToPath(svg) {
let els = svg.querySelectorAll('rect, circle, polygon');
els.forEach(function(el, i) {
let className = el.getAttribute('class');
let id = el.id;
let d = el.getAttribute('d');
let fill = el.getAttribute('fill');
let pathData = el.getPathData({
normalize: true
});
let pathTmp = document.createElementNS("http://www.w3.org/2000/svg", 'path');
pathTmp.id = id;
pathTmp.setAttribute('class', className);
pathTmp.setAttribute('fill', fill);
pathTmp.setPathData(pathData);
svg.insertBefore(pathTmp, el);
el.remove();
})
};
shapesToPath(svg);
function subtract(svg) {
// init paper.js and add mandatory canvas
canvas = document.createElement('canvas');
canvas.id = "canvasPaper";
canvas.setAttribute('style', 'display:none')
document.body.appendChild(canvas);
paper.setup("canvasPaper");
let all = paper.project.importSVG(svg, function(item, i) {
let items = item.getItems();
// remove first item not containing path data
items.shift();
// get id names for selecting svg elements after processing
let ids = Object.keys(item._namedChildren);
if (items.length) {
let lastEl = items[items.length - 1];
// subtract paper.js objects
let subtracted = items[0].subtract(lastEl);
// convert subtracted paper.js object to svg pathData
let subtractedData = subtracted
.exportSVG({
precision: 3
})
.getAttribute("d");
let svgElFirst = svg.querySelector('#' ids[0]);
let svgElLast = svg.querySelector('#' ids[ids.length - 1]);
// overwrite original svg path
svgElFirst.setAttribute("d", subtractedData);
// delete subtracted svg path
svgElLast.remove();
}
});
}svg {
display: inline-block;
width: 25%;
border: 1px solid #ccc
}<script src="https://cdn.jsdelivr.net/npm/[email protected]/path-data-polyfill.min.js"></script>
<script src="https://cdnjs.cloudflare.com/ajax/libs/paper.js/0.12.0/paper-full.min.js"></script>
<p>
<button type="button" onclick="subtract(svg)">Subtract Path </button>
</p>
<svg id="svgSubtract" viewBox="0 0 100 100">
<rect x="0" y="0" width="80" height="80" fill="red" />
<path d="M87.9,78.7C87.9,84,86,88,82.2,91c-3.8,2.9-8.9,4.4-15.4,4.4c-7,0-12.5-0.9-16.2-2.7v-6.7c2.4,1,5.1,1.8,8,2.4
c2.9,0.6,5.7,0.9,8.5,0.9c4.6,0,8.1-0.9,10.4-2.6c2.3-1.7,3.5-4.2,3.5-7.3c0-2.1-0.4-3.7-1.2-5.1c-0.8-1.3-2.2-2.5-4.1-3.6
c-1.9-1.1-4.9-2.4-8.8-3.8c-5.5-2-9.5-4.3-11.8-7c-2.4-2.7-3.6-6.2-3.6-10.6c0-4.6,1.7-8.2,5.2-10.9c3.4-2.7,8-4.1,13.6-4.1
c5.9,0,11.3,1.1,16.3,3.2l-2.2,6c-4.9-2.1-9.7-3.1-14.3-3.1c-3.7,0-6.5,0.8-8.6,2.4c-2.1,1.6-3.1,3.8-3.1,6.6
c0,2.1,0.4,3.7,1.1,5.1c0.8,1.3,2,2.5,3.8,3.6c1.8,1.1,4.6,2.3,8.3,3.6c6.2,2.2,10.5,4.6,12.9,7.1C86.7,71.4,87.9,74.7,87.9,78.7z"
/>
</svg>Path normalization (using getPathData() polyfill)
We need to convert svg primitives (<rect>, <circle>, <polygon>)
to <path> elements – at least when using paper.js Boolean operations.
This step is not needed for shapes natively created as paper.js objects.
The pathData polyfill provides a method of normalizing svg elements.
This normalization will output a d attribute (for every selected svg child element) containing only a reduced set of cubic path commands (M, C, L, Z) – all based on absolute coordinates.
Example 2 (multiple elements to be subtracted)
const svg = document.querySelector("#svgSubtract");
const btnDownload = document.querySelector("#btnDownload");
const decimals = 1;
// set auto ids for processing
function setAutoIDs(svg) {
let svgtEls = svg.querySelectorAll(
"path, polygon, rect, circle, line, text, g"
);
svgtEls.forEach(function(el, i) {
if (!el.getAttribute("id")) {
el.id = el.nodeName "-" i;
}
});
}
setAutoIDs(svg);
function shapesToPathMerged(svg) {
let els = svg.querySelectorAll('path, rect, circle, polygon, ellipse ');
let pathsCombinedData = '';
let className = els[1].getAttribute('class');
let id = els[1].id;
let d = els[1].getAttribute('d');
let fill = els[1].getAttribute('fill');
els.forEach(function(el, i) {
let pathData = el.getPathData({
normalize: true
});
if (i == 0 && el.nodeName.toLowerCase() != 'path') {
let firstTmp = document.createElementNS("http://www.w3.org/2000/svg", 'path');
let firstClassName = els[1].getAttribute('class');
let firstId = el.id;
let firstFill = el.getAttribute('fill');
firstTmp.setPathData(pathData);
firstTmp.id = firstId;
firstTmp.setAttribute('class', firstClassName);
firstTmp.setAttribute('fill', firstFill);
svg.insertBefore(firstTmp, el);
el.remove();
}
if (i > 0) {
pathData.forEach(function(command, c) {
pathsCombinedData = ' ' command['type'] '' command['values'].join(' ');
});
el.remove();
}
})
let pathTmp = document.createElementNS("http://www.w3.org/2000/svg", 'path');
pathTmp.id = id;
pathTmp.setAttribute('class', className);
pathTmp.setAttribute('fill', fill);
pathTmp.setAttribute('d', pathsCombinedData);
svg.insertBefore(pathTmp, els[0].nextElementSibling);
};
shapesToPathMerged(svg);
function subtract(svg) {
// init paper.js and add mandatory canvas
canvas = document.createElement('canvas');
canvas.id = "canvasPaper";
canvas.setAttribute('style', 'display:none')
document.body.appendChild(canvas);
paper.setup("canvasPaper");
let all = paper.project.importSVG(svg, function(item, i) {
let items = item.getItems();
// remove first item not containing path data
items.shift();
// get id names for selecting svg elements after processing
let ids = Object.keys(item._namedChildren);
if (items.length) {
let lastEl = items[items.length - 1];
// subtract paper.js objects
let subtracted = items[0].subtract(lastEl);
// convert subtracted paper.js object to svg pathData
let subtractedData = subtracted
.exportSVG({
precision: decimals
})
.getAttribute("d");
let svgElFirst = svg.querySelector('#' ids[0]);
let svgElLast = svg.querySelector('#' ids[ids.length - 1]);
// overwrite original svg path
svgElFirst.setAttribute("d", subtractedData);
// delete subtracted svg path
svgElLast.remove();
}
});
// get data URL
getdataURL(svg)
}
function getdataURL(svg) {
let markup = svg.outerHTML;
replaceAll('\t', '').
replaceAll('\n', '').
replaceAll('\r', '').
replaceAll('></path>', '/>').
replaceAll('<', '<').
replaceAll('>', '>').
replaceAll('#', '#').
replaceAll(',', ' ').
replaceAll(' -', '-').
replace(/ (?= )/g, '');
let btn = document.createElement('a');
btn.href = markupOpt;
btn.innerText = 'Download Svg';
btn.setAttribute('download', 'subtracted.svg');
document.body.insertAdjacentElement('afterbegin', btn);
return markupOpt;
}<script src="https://cdnjs.cloudflare.com/ajax/libs/paper.js/0.12.0/paper-full.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/[email protected]/path-data-polyfill.min.js"></script>
<p>
<button type="button" onclick="subtract(svg)">Subtract Path </button>
</p>
<svg id="svgSubtract" viewBox="0 0 100 100" xmlns="http://www.w3.org/2000/svg">
<rect x="0" y="0" width="80" height="80" fill="red" />
<path id="s"
d="M87.9,78.7C87.9,84,86,88,82.2,91c-3.8,2.9-8.9,4.4-15.4,4.4c-7,0-12.5-0.9-16.2-2.7v-6.7c2.4,1,5.1,1.8,8,2.4
c2.9,0.6,5.7,0.9,8.5,0.9c4.6,0,8.1-0.9,10.4-2.6c2.3-1.7,3.5-4.2,3.5-7.3c0-2.1-0.4-3.7-1.2-5.1c-0.8-1.3-2.2-2.5-4.1-3.6
c-1.9-1.1-4.9-2.4-8.8-3.8c-5.5-2-9.5-4.3-11.8-7c-2.4-2.7-3.6-6.2-3.6-10.6c0-4.6,1.7-8.2,5.2-10.9c3.4-2.7,8-4.1,13.6-4.1
c5.9,0,11.3,1.1,16.3,3.2l-2.2,6c-4.9-2.1-9.7-3.1-14.3-3.1c-3.7,0-6.5,0.8-8.6,2.4c-2.1,1.6-3.1,3.8-3.1,6.6
c0,2.1,0.4,3.7,1.1,5.1c0.8,1.3,2,2.5,3.8,3.6c1.8,1.1,4.6,2.3,8.3,3.6c6.2,2.2,10.5,4.6,12.9,7.1C86.7,71.4,87.9,74.7,87.9,78.7z" />
<path id="o" d="M30.2,22.4c0,8.3-5.8,12-11.2,12c-6.1,0-10.8-4.5-10.8-11.6c0-7.5,4.9-12,11.2-12C25.9,10.8,30.2,15.5,30.2,22.4z
M12.4,22.6c0,4.9,2.8,8.7,6.8,8.7c3.9,0,6.8-3.7,6.8-8.7c0-3.8-1.9-8.7-6.7-8.7C14.5,13.8,12.4,18.3,12.4,22.6z" />
<circle cx="50%" cy="50%" r="10%"></circle>
</svg>CodePudding user response：
This is a nontrivial problem in general.
It can be solved easily (little code) if you can accept rasterizing the shapes to pixels, perform the boolean operation there, and then vectorize back the result using marching squares simplification.
Known algorithms to compute instead a somewhat exact* geometric result are quite complex and difficult to implement correctly while keeping them fast.
Clipper is an easy to use library to perform this kind of computation in C , with ports to Javascript.
(*) The coordinates of the intersection of two segments with integer coordinates cannot, in general, be represented exactly by double-precision numbers; thus the result will still be an approximation unless you use a numeric library with support for rationals.
